Kenwood DNX570HD User Manual

104104 105
Return to the Top page
Audio Setting Up
Return to the Top page
Audio Setting Up
Controlling General Audio
1 Touch [Audio Control].


2 Set each item as follows.
Fader #/Balance #
Adjust the volume balance around the
touched area.
[2] and [3] adjust the right and left volume
balance.
[5] and [∞] adjust the front and rear volume
balance.
Volume Offset*
Finely adjust the volume of the current source
to minimize the difference in volume between
different sources.
Subwoofer Level
Adjusts the subwoofer volume. This setting is
not available when subwoofer is set to “None”.
See Speaker setup (P.101).
Bass Boost
Sets the amount of bass boost among “OFF”/
“Level1”/ “Level2”/ “Level3”.
Loudness
Turns the loudness control function on or
off. If turned on, high and low tones are
automatically enhanced during low volume.
Settable only when zone function (P.107) is set
to off.
*Ifyouhaveincreasedthevolumefirst,then
reducedthevolumeusingthe“Volume
Offset”,thesoundgeneratedifyou
suddenlyswitchtoanothersourcemaybe
extremelyloud.
Equalizer Control
Youcanadjustequalizerbyselectingthe
optimizedsettingforeachcategory.
Ifyouuse
 ,youcanalsoadjust
equalizermanually.
1 Touch [Equalizer].


Equalizer screen appears.
Operation
Controlling EQ curves
1 Select EQ curve from [Natural],
[Rock], [Pops], [Easy], [Top40], [Jazz],
[Powerful], [iPod], and [User].
NOTE
• [iPod] is available only during iPod source.
Controlling equalizer manually
Thissettingcannotbeperformedwhenyou
select[iPod]intheEqualizerscreen.
1 Touch [EQ] in the Equalizer screen.
2 Touch the screen and set the Graphic
Equalizer as desired.
Gain level (light green boxed area)
Adjust the gain level by touching the each
frequency bar.
Touching [2], [3], [5] and [∞] can also
adjust the level. Use [2] and [3] to select a
frequency, and [5] and [∞] to set the level.
EQ INIT
Returns to the previous level which the gain
level is adjusted.
Flat
Tone curve becomes flat.
Bass EXT (Bass Extend Settings)
When turned on, the frequency lower than
62.5 Hz is set to the same gain level as 62.5 Hz.
Loudness
Sets the amounts of boost of low and high
tones. “OFF”, “Low”, “High”
SW Level
Adjusts the subwoofer volume. This setting is
not available when subwoofer is set to “None”.
See Speaker setup (P.101).

Kenwood DNX570HD Specifications

General

Resolution	800 x 480 pixels
GPS Navigation	Yes
Bluetooth	Yes
USB Ports	1
HD Radio	Yes
Apple CarPlay	No
Android Auto	No
DVD Player	Yes
SD Card Slot	Yes
CD Player	Yes
iPod/iPhone Control	Yes
Steering Wheel Control	Yes
Backup Camera Input	Yes
Audio Formats Supported	MP3, WMA, AAC
Video Formats Supported	MPEG-1, MPEG-2, MPEG-4, WMV
SiriusXM	Yes (with optional tuner)
