Kenwood DPF-1010 User Manual

DPF-1010/1010E/2010/2010E/3010/3010E
14
PARTS LIST
601 1D A01-3356-08 METALLIC CABINET
602 1C A09-0356-08 BATTERY COVER
603 2C ✽ A21-3697-08 DRESSING PANEL
604 2C ✽ A60-1488-08 PANEL DPF-3010 3
604 2C ✽ A60-1489-08 PANEL DPF-2010 2
604 2C ✽ A60-1490-08 PANEL DPF-1010 1
605 1C A70-1181-08 REMOCON (RC-P0305)
611 2C ✽ B10-3413-08 FRONT GLASS
612 2C B43-0302-04 KENWOOD BADGE
- B46-0310-03 WARRANTY CARD ET
- ✽ B60-3730-08 INST MANUAL ENGLISH TEMX
- ✽ B60-3731-08 INST MANUAL FRENCH/ITALIAN E
- ✽ B60-3732-08 INST MANUAL DUTCH/GERMAN E
- ✽ B60-3733-08 INST MANUAL SPANISH EM
- ✽ B60-3734-08 INST MANUAL TAIWANESE M
- H25-1601-08 PROTECTION BAG (260X390)
- 550000017000 LABEL
- 550001593000 LABEL(LASER CAUTION)
616 1C E03-0115-05 AC PLUG ADAPTOR M
617 1C E30-2733-05 SYSTEM CONTROL CORD
618 1C E30-2841-08 AUDIO CORD
619 1E E30-2872-08 AC POWER CORD X
619 1E E30-2873-08 AC POWER CORD EM
619 1E ✽ E30-2888-08 AC POWER CORD T
620 1E,1D ✽ E35-2198-08 FLAT CABLE (29P)
621 1E ✽ E35-2222-08 FLAT CABLE (16P)
- ✽ H10-7506-08 POLYSTYRENE FOAMED FIXTURE
- ✽ H25-1634-08 PROTECTION BAG (700X650)
- ✽ H50-2857-08 ITEM CARTON CASE 3010 E 3
- ✽ H50-2858-08 ITEM CARTON CASE 3010 T 3
- ✽ H50-2859-08 ITEM CARTON CASE 2010 E 2
- ✽ H50-2860-08 ITEM CARTON CASE 2010 TX 2
- ✽ H50-2861-08 ITEM CARTON CASE 2010 M 2
- ✽ H50-2862-08 ITEM CARTON CASE 1010 E 1
- ✽ H50-2863-08 ITEM CARTON CASE 1010 TX 1
- ✽ H50-2864-08 ITEM CARTON CASE 1010 M 1
624 2D G11-2265-08 FOOT(CUSHION)
628 2E J02-1166-08 FOOT(ABS BK)
629 2D J02-1421-08 FOOT(STAMPING)
630 1E J19-5725-08 PCB SUPPORTER
631 2D ✽ J32-0340-08 FOOT(MECHA)
632 1E J42-0200-08 POWER CORD BUSHING
636 2C ✽ K29-7372-08 KNOB(POWER)
637 2C ✽ K29-7373-08 KNOB(FUNCTION)
638 2C ✽ K29-7374-08 KNOB(10KEY)
639 2D ✽ K29-7375-08 KNOB(PLAY)
C N09-3095-08 SCREW TAP TITE 4X8ZN
C100-106 CK45FF1H473Z CERAMIC 0.047UF Z
C107,108 CE04KW1E471M ELECTRO 470UF 25WV
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East, Hawaii) T : Europe E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components.
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East, Hawaii) T : Europe E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components.
C114 CE04KW1H101M ELECTRO 100UF 50WV
C115 CK45FF1H473Z CERAMIC 0.047UF Z
C116 CE04KW1H101M ELECTRO 100UF 50WV
C117,118 CK45FF1H103Z CERAMIC 0.010UF Z
C119 CE04KW1H010M ELECTRO 1.0UF 50WV
C120 CK45FF1H103Z CERAMIC 0.010UF Z
C121 CE04KW1E470M ELECTRO 47UF 25WV
C201 CE04KW1E470M ELECTRO 47UF 25WV
C203 CE04KW1A101M ELECTRO 100UF 10WV
C204 CK45FF1H102K CERAMIC 1000PF K
C205 CE04KW1A101M ELECTRO 100UF 10WV
C207 CC45FSL1H150J CERAMIC 15PF J
C209 CK45FF1H473Z CERAMIC 0.047UF Z
C210 CE04KW1H010M ELECTRO 1.0UF 50WV
C302 CK14B1H103K CERAMIC AXIAL 0.010UF K
C306 CK14B1H103K CERAMIC AXIAL 0.010UF K
C307 C91-0757-05 CERAMIC 1000PF K
C400 CE04KW1A101M ELECTRO 100UF 10WV
C401 CE04KW0J471M ELECTRO 470UF 6.3WV
C402 CQ92FM1H683J MYLAR 0.068UF J
C421,422 CC45FSL1H101J CERAMIC 100PF J
C423 CQ92FM1H104J MYLAR 0.10UF J
C501 CC45FSL1H471J CERAMIC 470PF J
C502 CE04KW2A100M ELECTRO 10UF 100WV
C503 CC45FSL1H471J CERAMIC 470PF J
C504 CK45FF1H103Z CERAMIC 0.010UF Z
C505 CE04KW1A101M ELECTRO 100UF 10WV 1,2
C506,507 CC45FSL1H121J CERAMIC 120PF J 1,2
C508,509 CE04KW1H100M ELECTRO 10UF 50WV 1,2
C510.511 CQ92FM1H222J MYLAR 2200PF J 1,2
C512 CK45FF1H103Z CERAMIC 0.010UF Z 1,2
C513 CC45FSL1H101J CERAMIC 100PF J 1,2
C514,515 CE04KW1C220M ELECTRO 22UF 16WV 1.2
C517 CQ92FM1H152J MYLAR 1500PF J
C518 CQ92FM1H473J MYLAR 0.047UF J
C519 CQ92FM1H332J MYLAR 3300PF J
C520 CK45FF1H103Z CERAMIC 0.010UF Z
C521 CQ92FM1H104J MYLAR 0.10UF J
C522,523 CC45FSL1H270J CERAMIC 27PF J 1,2
C524,525 CE04KW1A101M ELECTRO 100UF 10WV
C526 CE04KW1E470M ELECTRO 47UF 25WV
C530,531 CK45FB1H561K CERAMIC 560PF K 1,2
C532 CQ92FM1H103J MYLAR 0.010UF J
C533,534 CC45FSL1H470J CERAMIC 47PF J 1,2
C535-538 CK45FB1H561K CERAMIC 560PF K 1,2
C539,540 CC45FSL1H471J CERAMIC 470PF J 1,2
C541,542 CK45FB1H561K CERAMIC 560PF K 1,2
C602 CK45FF1H103Z CERAMIC 0.010UF Z
C603 CE04KW1H010M ELECTRO 1.0UF 50WV
C606 CE04KW1A331M ELECTRO 330UF 10WV
C607 CK14DB1H471K CERAMIC 470PF K
C651,652 C91-0749-05 CERAMIC 220PF K
C653 CK45FF1H103Z CERAMIC 0.010UF Z
C701,702 CE04KW0J471M ELECTRO 470UF 6.3WV 3
C705 CE04KW1A221M ELECTRO 220UF 10WV 3
✽
New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
2
Ref. No
Add-
ress
New
Parts
Parts No. Description
Desti-
nation
Re-
marks
✽
New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
1
Ref. No
Add-
ress
New
Parts
Parts No. Description
Desti-
nation
Re-
marks
DPF-1010/2010/3010
ELECTRIC PARTS
DPF-1010(K) COVER-2P( 98.11.30 3:55 PM y[W 5
