Kenwood DPF-1010 User Manual

MODEL ABB. Australia Canada China England Europe Germany Korea Malaysia
DPF-1010 1 X - - T E - - - DPF-2010 2 X - - T E - - - DPF-3010 3 - - - T E - - -
MODEL ABB. Mexico PX/AAFES Russia Scandinavia Shanghai USA Other area
DPF-1010 1 ------M- DPF-2010 2 ------M- DPF-3010 3 --------
DPF-1010/1010E/2010/2010E/3010/3010E
PARTS LIST / SPECIFICATIONS
[ Format ]
System ......................................Compact disc digital audio system
Laser ..................................................................Semiconductor laser
[ D/A Convertors ]
D/A Conversion ............................................................................1 Bit
Oversampling ............................................................ 8 fs (352.8 kHz)
[ Audio ] (for DPF-3010)
Frequency response ...................................... 4 Hz ~ 20 kHz, ±0.5 dB
Signal to noise ratio............................................. More than 100 dB
Dynamic range ....................................................... More than 95 dB
Total harmonic distortion + noise ...... Less than 0.006% (at 1 kHz)
Channel separation ............................... More than 95 dB (at 1 kHz)
Wow & flutter ................................................... Unmeasurable Limit
Output level/impedance
Variable ........................................................ (Max.) 2.0 V/0.8 kΩ
Digital output
Optical ........................................................–15 dBm – –21 dBm
(Wave length 660 nm)
[ Audio ] (for DPF-2010/1010)
Frequency response ...................................... 6 Hz ~ 20 kHz, ±0.5 dB
Signal to noise ratio............................................... More than 94 dB
Dynamic range ....................................................... More than 92 dB
Total harmonic distortion + noise ..... Less than 0.007% (at 1 kHz)
Channel separation ............................... More than 90 dB (at 1 kHz)
Wow & flutter ................................................... Unmeasurable Limit
Output level/impedance
V
Fixed
ariable (only DPF-2010)
(only DPF-1010)
Digital output
(only DPF-2010)
..................
..............................
(Max.) 2.0 V/0.8 kΩ
2.0 V/0.8 kΩ
Optical ........................................................–15 dBm – –21 dBm
(Wave length 660 nm)
Australia, Europe and U.K.
Other countries
..................................................
.....................................................................
Headphone output (Max.) .......................................... 20 mW (32 Ω)
[ General ]
Power consumption
12 W
14 W
Dimensions ................................................... W : 440 mm (17-5/16")
H : 95 mm (3-3/4")
D : 370 mm (14-9/16")
Weight (Net) ................................................................. 4.3 kg (9.5 lb)
1. KENWOOD follows a policy of continuous
advancements in development. For this reason specifications may be changed without notic e.
2. The full performance may not be exhibited in an extremely cold location (under a water-freezing temperature).
Notes
Notes
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East, Hawaii) T : Europe E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components.
26 2B G09-0657-08 SPRING RACK 30 2A G11-2367-08 INSULATOR(4B,GREEN) 31 2A G11-2368-08 INSULATOR(30,RED) 32 2B J11-0829-08 CLAMPER 33 1B J21-6409-08 PLATE CLAMPER 34 2A J90-0853-08 GUIDE FRAME 36 3A J99-0600-08 TRAY 41 3B J31-0874-08 HOLDER S/W AB N09-3303-08 SCREW AC N09-3302-08 SCREW WPH 3X8 AD N09-3301-08 SCREW 40 3B S74-0068-08 SWITCH LEAF 42 2A S74-0038-08 LEAF SWITCH 17 3B D15-0395-08 PULLEY MOTOR 45 1B T99-0579-08 MAGNET CORE DM 1A A11-1082-18 DISC MOTOR ASSY FM 2A T42-0817-08 FEED MOTOR ASSY LM 3B T42-0855-08 MOTOR,DC PU 1A T25-0055-08 PICK UP (KSS-213C)
✽
New Parts
Parts without Parts No. are not supplied. Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
5
Ref. No
Add-
ress
New
Parts
Parts No. Description
Desti-
nation
Re-
marks
Note:
Component and circuit are subject to modification to insure best operation
under differing local conditions. This manual is based on Europe (E) standard,
and provides information on regional circuit modification through use of alter-
nate schematic diagrams, and information on regional component variations
through use of parts list.
14-6,Dogenzaka 1-chome, Shibuya-ku, Tokyo, 150-8501 Japan
KENWOOD SERVICE CORPORATION
P.O BOX 22745, 2201 East Dominguez St., Long Beach, CA 90801-5745, U.S.A.
Specifications
HOW TO READ THE PARTS LIST ABBREVIATION OF MODEL AND MASS PRODUCTION'S DESTINATIONS
DPF-1010(K) COVER-2P( 98.11.30 3:55 PM y[W 1
