DPF-1010/1010E/2010/2010E/3010/3010E
3
CIRCUIT DESCRIPTION
Pin No. Pin name I/O Description
1 GFS I NOT USED
2 RMC I REMOCON INPUT PORT
3-5 PE5~7 – NOT USED
6 MUTE O DIGITAL MUTE (ON : "H") DPF-1010/2010 ONLY
7 MLEN O TC9423F LATCH CONTROL
8 MCK O TC9423F CLOCK CONTROL
9 SENS I SENSE INPUT FROM CXD2587Q
10 MDT O TC9423F DATA CONTROL
11 SQCK O CLOCK TO READ Q_DATA
12 SUBQ I Q_DATA INPUT PORT
13 PB7 O NOT USED
14-17 KR0-KR3 I KEY INPUT PORT
18 OPEN_M O OPEN MOTOR (ACTIVE "L")
19 CLOSE_M O CLOSE MOTOR (ACTIVE "L")
20 MON O SPINDLE MOTOR ON "H"
21 PC7 O NOT USED
22 DATA O DATA OUT TO CXD2587Q
23 XLT O LATCH OUT TO CXD2587Q
24 CLK O CLOCK OUT TO CXD2587Q
25 FOK I FOCUS OK INPUT PORT
26 LDON O LASER OUTPUT (ON : "L")
27 A_MUTE O ANALOGUE MUTE (ON : "H")
28 XRST O IC RESET PORT
29 PA7 I OPTION L : DPF-1010/2010 H : DPF-3010
30 RESET – (RESET)
31 XI – (XTAL1) 4.19 MHz
32 XO – (XTAL0) 4.19 MHz
33 Vss – (GND)
34-46 – O NOT USED
47-57 SEG11~SEG1 O FL SEGMENT PORT (SEG11~SEG1) / KEY SCAN KS10~KS4 (48PIN~54PIN)
58-61 – O NOT USED
62-70 G9-G1 O FL DIGIT PORT
71 Vfdp – FL DRIVER POWER (-26V)
72 Vdd – (+5V)
73 NC – CONNECTED TO Vdd
74 FED_SW I LIMIT SWITCH (ON : "L")
75 MODE_SW I 8/16BIT (L : 8BIT , H : 16BIT)
76 S_DATA I/O SYSTEM SERIAL DATA
77 S_BUSY I/O SYSTEM SERIAL BUSY
78 SCCR I SCOR FROM CXD2587
79 OP_SW I OPEN SWITCH (ON : "L")
80 CL_SW I CLOSE SWITCH (ON : "L")
1. Microprocessor : CXP82324 (MAIN unit : IC601)
1-1 Pin description
KS10 (48pin) KS9 (49pin) KS8 (50pin) KS7 (51pin)
KR0 (14pin) 2 4 3
5
—
—
KR1 (15pin) 8 10 REPEAT —
KR2 (16pin)
4‰
II STOP RANDOM
KR3 (17pin) EDIT CLEAR TIME —
PEAK SEARCH
¡
7
6
KS6 (52pin)
CHECK
¢
0
5
KS5 (53pin)
PROGRAM
1
9
1
KS4 (54pin)
2. Key matrix
