Kenwood M-A100 Service Manual

M-A100/A300
PARTS LIST
17
New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
Ref. No
Add-
ress
New
Parts
Description
Desti-
nation
Re-
marks
Parts No.
L : Scandinavia K : USA P : Canada R : Mexico I : Malaysia 100 : M-A100
Y : PX(Far East, Hawaii) T : Europe E : Europe G : Germany C : China 300 : M-A300
Y : AAFES(Europe) X : Australia M : Other Areas
indicates safety critical components.
New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
Ref. No
Add-
ress
New
Parts
Description
Desti-
nation
Re-
marks
Parts No.
L : Scandinavia K : USA P : Canada R : Mexico I : Malaysia 100 : M-A100
Y : PX(Far East, Hawaii) T : Europe E : Europe G : Germany C : China 300 : M-A300
Y : AAFES(Europe) X : Australia M : Other Areas
indicates safety critical components.
W203,204 300 E31-0001-00 JUMPER WIRE YTECIM
W207,208 300 E31-0001-00 JUMPER WIRE
W209 100 E31-0001-00 JUMPER WIRE
F4 F05-8013-05 FUSE (SEMKO) (250V T800MAL) X
F4 F05-8013-05 FUSE (SEMKO) (250V T800MAL) YTECIM
F4 F50-0066-05 FUSE(5X20) KP
CN29,30 J13-0075-05 FUSE CLIP
J4 J21-5845-04 MOUNTING HARDWARE
L1 ,2 L39-0085-05 PHASE COMPENSATION COIL
L3 ,4 300 L39-0085-05 PHASE COMPENSATION COIL
L5 ,6 L39-0085-05 PHASE COMPENSATION COIL
R4 RD14NB2E102J RD 1.0K J 1/4W
R8 RS14KB3A182J FL-PROOF RS 1.8K J 1W X
R8 RS14KB3A182J FL-PROOF RS 1.8K J 1W YTECIM
R8 RS14KB3A222J FL-PROOF RS 2.2K J 1W KP
R18 RS14KB3A222J FL-PROOF RS 2.2K J 1W
R101,102 RD14NB2E470J RD 47 J 1/4W
R103,104 300 RD14NB2E470J RD 47 J 1/4W
R105-108 RD14NB2E470J RD 47 J 1/4W
R109,110 300 RD14NB2E470J RD 47 J 1/4W
R111,112 RD14NB2E470J RD 47 J 1/4W
R113,114 RD14NB2E101J RD 100 J 1/4W
R115,116 300 RD14NB2E101J RD 100 J 1/4W
R117,118 RD14NB2E101J RD 100 J 1/4W
R121,122 300 RD14BB2C272J RD 2.7K J 1/6W
R127,128 300 RD14BB2C621J RD 620 J 1/6W
R133,134 300 RD14BB2C471J RD 470 J 1/6W
R139,140 300 RD14BB2C103J RD 10K J 1/6W
R145,146 300 RD14BB2C103J RD 10K J 1/6W
R149,150 RS14KB3D3R9J FL-PROOF RS 3.9 J 2W
R151,152 300 RS14KB3D3R9J FL-PROOF RS 3.9 J 2W
R153,154 RS14KB3D3R9J FL-PROOF RS 3.9 J 2W
R155,156 RD14NB2E100J RD 10 J 1/4W
R157,158 300 RD14NB2E100J RD 10 J 1/4W
R159,160 RD14NB2E100J RD 10 J 1/4W
R201,202 RS14KB3D561J FL-PROOF RS 560 J 2W
R216 RS14KB3A222J FL-PROOF RS 2.2K J 1W
R221 RS14KB3D561J FL-PROOF RS 560 J 2W
R232 100 RS14KB3D271J FL-PROOF RS 270 J 2W
R232 300 RS14KB3D561J FL-PROOF RS 560 J 2W
R234 RS14KB3D561J FL-PROOF RS 560 J 2W
R302 RS14KB3A222J FL-PROOF RS 2.2K J 1W
VR1 ,2 R12-0605-05 TRIMMING POT.(220)
VR3 ,4 300 R12-0605-05 TRIMMING POT.(220)
VR5 ,6 R12-0605-05 TRIMMING POT.(220)
K1 -4 S76-0056-05 MAGNETIC RELAY
K5 S76-0063-05 MAGNETIC RELAY
S10 2A S40-1094-05 PUSH SWITCH (POWER TYPE)
TS1 ,2 100 S51-1518-05 RELAY ASSY
TS1 ,2 300 S79-0020-05 THERMAL SWITCH
D1 -4 S5688B DIODE
D1 -4 1SR139-400 DIODE
D5 D5SBA20F03 DIODE
C23 CE04KW1H471M ELECTRO 470UF 50WV
C24 -27 CK45FE2H103P CERAMIC 0.010UF P
C101,102 CK45FF1H103Z CERAMIC 0.010UF Z
C103,104 300 CK45FF1H103Z CERAMIC 0.010UF Z
C105,106 CK45FF1H103Z CERAMIC 0.010UF Z
C107,108 CF92FV1H334J MF-C 0.33UF J X
C107,108 CF92FV1H334J MF-C 0.33UF J YTECIM
C107,108 CF92FV1H564J MF-C 0.56UF J KP
C109,110 300 CF92FV1H334J MF-C 0.33UF J X
C109,110 300 CF92FV1H334J MF-C 0.33UF J YTECIM
C109,110 300 CF92FV1H564J MF-C 0.56UF J KP
C111,112 CF92FV1H334J MF-C 0.33UF J X
C111,112 CF92FV1H334J MF-C 0.33UF J YTECIM
C113,114 CQ93FMG1H473J MYLAR 0.047UF J
C115,116 300 CQ93FMG1H473J MYLAR 0.047UF J
C117,118 CQ93FMG1H473J MYLAR 0.047UF J
C119 300 CK45FF1H472Z CERAMIC 4700PF Z
C120 CK45FF1H472Z CERAMIC 4700PF Z
C121 300 CK45FF1H472Z CERAMIC 4700PF Z
C122 CK45FF1H472Z CERAMIC 4700PF Z
C123 300 CK45FF1H472Z CERAMIC 4700PF Z
C124 CK45FF1H472Z CERAMIC 4700PF Z
C125,126 100 CK45FF1H472Z CERAMIC 4700PF Z
C201 CE04KW1C220M ELECTRO 22UF 16WV
C202 CE04KW1A221M ELECTRO 220UF 10WV
C203 CK45FF1H223Z CERAMIC 0.022UF Z
C204 CE04KW1H4R7M ELECTRO 4.7UF 50WV
C205 CE04KW1H330M ELECTRO 33UF 50WV
C206 CC45FSL1H221J CERAMIC 220PF J
C207 CE04KW1H010M ELECTRO 1.0UF 50WV
C208 CE04KW1V330M ELECTRO 33UF 35WV
C211,212 CF92FV1H564J MF-C 0.56UF J KP
C213,214 300 CF92FV1H564J MF-C 0.56UF J KP
C215,216 CF92FV1H564J MF-C 0.56UF J KP
C301 C91-1488-05 MF 6800PF 250VAC
C302-306 CK45FE2H103P CERAMIC 0.010UF P
C307 CE04KW2A4R7M ELECTRO 4.7UF 100WV
CN1 ,2 E40-9842-05 PIN ASSY
CN3 E40-9841-05 PIN ASSY
CN4 E40-9844-05 PIN ASSY
CN5 ,6 E40-3246-05 PIN ASSY
CN7 E40-3247-05 PIN ASSY
CN11,12 E40-4871-05 PIN ASSY
CN13,14 300 E40-4871-05 PIN ASSY
CN15,16 E40-4871-05 PIN ASSY
CN101 E40-4245-05 PIN ASSY CIMX
CN101 E40-8126-05 PIN ASSY KPYTE
CN102 E40-4281-05 PIN ASSY CIMX
CN102 E40-8129-05 PIN ASSY KPYTE
J1 300 E70-0046-05 LOCK TERMINAL BOARD
J2 E70-0046-05 LOCK TERMINAL BOARD
J3 100 E70-0045-05 LOCK TERMINAL BOARD CIMX
J3 100 E70-0053-05 LOCK TERMINAL BOARD KPYTE
W203,204 300 E31-0001-00 JUMPER WIRE X
3 4
1p~3p/19p~22p 97.6.2 4:52 PM y[W 17
