Kenwood M-A100 Service Manual

PARTS LIST
M-A100/A300
18
New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
Ref. No
Add-
ress
New
Parts
Description
Desti-
nation
Re-
marks
Parts No.
L : Scandinavia K : USA P : Canada R : Mexico I : Malaysia 100 : M-A100
Y : PX(Far East, Hawaii) T : Europe E : Europe G : Germany C : China 300 : M-A300
Y : AAFES(Europe) X : Australia M : Other Areas
indicates safety critical components.
New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
Ref. No
Add-
ress
New
Parts
Description
Desti-
nation
Re-
marks
Parts No.
L : Scandinavia K : USA P : Canada R : Mexico I : Malaysia 100 : M-A100
Y : PX(Far East, Hawaii) T : Europe E : Europe G : Germany C : China 300 : M-A300
Y : AAFES(Europe) X : Australia M : Other Areas
indicates safety critical components.
Q105,106 100 TRAITR3N TRANSISTOR TE
Q105,106 300 TRAITR4N TRANSISTOR
Q105,106 100 TRAITR4N TRANSISTOR KPYCIM
Q105,106 100 TRAITR4N TRANSISTOR X
Q107,108 100 TRAITR3P TRANSISTOR TE
Q107,108 300 TRAITR4P TRANSISTOR
Q107,108 100 TRAITR4P TRANSISTOR KPYCIM
Q107,108 100 TRAITR4P TRANSISTOR X
Q109,110 300 TRAITR4P TRANSISTOR
Q111,112 100 TRAITR3P TRANSISTOR TE
Q111,112 300 TRAITR4P TRANSISTOR
Q111,112 100 TRAITR4P TRANSISTOR KPYCIM
Q111,112 100 TRAITR4P TRANSISTOR X
Q113,114 2SC1845(F,E) TRANSISTOR
Q115,116 300 2SC1845(F,E) TRANSISTOR
Q117,118 2SC1845(F,E) TRANSISTOR
Q201,202 2SC2003(L,K) TRANSISTOR
Q203 2SA992(F,E) TRANSISTOR
Q204 2SA954(L,K) TRANSISTOR
Q205 2SC1740S(Q,R) TRANSISTOR CIMX
Q205 2SC2458(Y,GR) TRANSISTOR KPYTE
Q205 2SC2785(F,E)) TRANSISTOR CIMX
Q205 2SC3311A(Q,R) TRANSISTOR KPYTE
Q206 2SC2003(L,K) TRANSISTOR
Q207,208 100 2SC1740S(Q,R) TRANSISTOR CIMX
Q207,208 300 2SC2458(Y,GR) TRANSISTOR
Q207,208 100 2SC2458(Y,GR) TRANSISTOR KPYTE
Q207,208 100 2SC2785(F,E) TRANSISTOR CIMX
Q207,208 300 2SC3311A(Q,R) TRANSISTOR
Q207,208 100 2SC3311A(Q,R) TRANSISTOR KPYTE
Q301-303 2SC1740S(Q,R) TRANSISTOR CIMX
Q301-303 2SC2458(Y,GR) TRANSISTOR KPYTE
Q301-303 2SC2785(F,E) TRANSISTOR CIMX
Q301-303 2SC3311A(Q,R) TRANSISTOR KPYTE
C1 ,2 CE04KW1H4R7M ELECTRO 4.7UF 50WV
C3 ,4 300 CE04KW1H4R7M ELECTRO 4.7UF 50WV
C5 ,6 CE04KW1H4R7M ELECTRO 4.7UF 50WV
C7 ,8 CK45FB1H681K CERAMIC 680PF K
C9 ,10 300 CK45FB1H681K CERAMIC 680PF K
C11 ,12 CK45FB1H681K CERAMIC 680PF K
C25 ,26 CE04KW1A101M ELECTRO 100UF 10WV
C27 ,28 300 CE04KW1A101M ELECTRO 100UF 10WV
C29 ,30 CE04KW1A101M ELECTRO 100UF 10WV
C31 ,32 CC45FSL2H680J CERAMIC 68PF J
C33 ,34 300 CC45FSL2H680J CERAMIC 68PF J
C35 ,36 CC45FSL2H680J CERAMIC 68PF J
C37 ,38 CC45FSL2H470J CERAMIC 47PF J
C39 ,40 300 CC45FSL2H470J CERAMIC 47PF J
C41 ,42 CC45FSL2H470J CERAMIC 47PF J
C43 ,44 CE04KW2A470M ELECTRO 47UF 100WV
C45 100 CK45FF1H103Z CERAMIC 0.010UF Z
C46 CE04KW2A221M ELECTRO 220UF 100WV
C47 CE04KW1E470M ELECTRO 47UF 25WV
C48 CE04KW1C470M ELECTRO 47UF 16WV
D5 RBV-602LFA DIODE
D9 HZS13N(B2) ZENER DIODE KPYTE
D9 MTZJ13(B) ZENER DIODE CIMX
D9 RD13ES(B2) ZENER DIODE KPYTE
D9 UZ-13BSB ZENER DIODE CIMX
D10 HZS11N(B2) ZENER DIODE KPYTE
D10 MTZJ11(B) ZENER DIODE CIMX
D10 RD11ES(B2) ZENER DIODE KPYTE
D10 UZ-11BSB ZENER DIODE CIMX
D11 S15VB20 DIODE
D12 HSS104A DIODE
D12 1SS131 DIODE
D13 ,14 HZS13N(B2) ZENER DIODE KPYTE
D13 ,14 MTZJ13(B) ZENER DIODE CIMX
D13 ,14 RD13ES(B2) ZENER DIODE KPYTE
D13 ,14 UZ-13BSB ZENER DIODE CIMX
D19 HZS4.7N(B2) ZENER DIODE KPYTE
D19 MTZJ4.7(B) ZENER DIODE CIMX
D19 RD4.7ES(B2) ZENER DIODE KPYTE
D19 UZ-4.7BSB ZENER DIODE CIMX
D101,102 HSS104A DIODE
D101,102 1SS131 DIODE
D103,104 300 HSS104A DIODE
D103,104 300 1SS131 DIODE
D105-108 HSS104A DIODE
D105-108 1SS131 DIODE
D109,110 300 HSS104A DIODE
D109,110 300 1SS131 DIODE
D111,112 HSS104A DIODE
D111,112 1SS131 DIODE
D201-207 HSS104A DIODE
D201-207 1SS131 DIODE
D208 HZS13N(B2) ZENER DIODE KPYTE
D208 MTZJ13(B) ZENER DIODE CIMX
D208 RD13ES(B2) ZENER DIODE KPYTE
D208 UZ-13BSB ZENER DIODE CIMX
D209,210 HSS104A DIODE
D209,210 1SS131 DIODE
IC1 UPC1237HA IC(POWER AMP)
Q1 2SC3940A(R,S) TRANSISTOR
Q3 ,4 2SC1740S(Q,R) TRANSISTOR CIMX
Q3 ,4 2SC2458(Y,GR) TRANSISTOR KPYTE
Q3 ,4 2SC2785(F,E) TRANSISTOR CIMX
Q3 ,4 2SC3311A(Q,R) TRANSISTOR KPYTE
Q5 2SD2012 TRANSISTOR
Q5 2SD2061 TRANSISTOR
Q6 -8 2SC1740S(Q,R) TRANSISTOR CIMX
Q6 -8 2SC2458(Y,GR) TRANSISTOR KPYTE
Q6 -8 2SC2785(F,E) TRANSISTOR CIMX
Q6 -8 2SC3311A(Q,R) TRANSISTOR KPYTE
Q101,102 100 TRAITR3N TRANSISTOR TE
Q101,102 300 TRAITR4N TRANSISTOR
Q101,102 100 TRAITR4N TRANSISTOR KPYCIM
Q101,102 100 TRAITR4N TRANSISTOR X
Q103,104 300 TRAITR4N TRANSISTOR
5 6
CONTROL (X11-3740-10/X11-3773-00)
1p~3p/19p~22p 97.6.2 4:52 PM y[W 18
