Kenwood MDX-01 User Manual

12
A BDCE
2
1
3
5
7
4
6
Refer to the schematic diagram for the value of resistors and capacitors.
PC BOARD
(
Component side view
)
R504A
R505A
R514A
R513A
R517A
R518A
R519A
R516A
R515A
R520A
R512A
R510A
R508A
R507A
R509A
R503A
R502A
R501A
R511A
R506A
CN802
R813A
110
R814B
R811A
R810A
R815A
C808A
R801A C807A R802A C802A
R803A C804A R804A C803A
R809A
R808A
R807A
R806A
J503
J508
J504
J502
CDTUNER MD
POWER
SKIP DOWN
CD DOOR
STOP
VOL. DOWN
VOL. UP
SOUNDSET / DEMOMENU
REPEAT MD REC. BEST HITS
SKIP UP
J501
J505 J506
J507
E
8
1
E
BB
SW513
Q501
Q502
SW512
SW514
CN501
SW516
SW508
SW507 SW511
SW501
SW502SW509SW504
D502
SW515
SW506
SW505
KEY UNIT
SW510 SW503
SW801
D802
D801
IC801
VR801
MD EJECT
J802
10
13
1
J802
C809
CN801
DISPLAY UNIT
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299

Kenwood MDX-01 Specifications

Amplifier Section

maximum practical output	2 W + 2 W (EIAJ, 4 Ω)

Tuner Section

FM tuning frequency range	87.5 MHz ~ 108 MHz
AM tuning frequency range	531 kHz ~ 1, 602 kHz

CD Player Section

D/A conversion	1 Bit
sampling frequency	8 fs (352.8 kHz)
frequency response	20 Hz to 20, 000 Hz

MD Recorder Section

laser wave length	765 to 805 nm
laser power class	Class 3B
audio compression method	ATRAC

Speakers

enclosures	Bass-reflex type
speaker units	80 mm, cone type
reading method	Non-contact optical read (using a laser diode)

Power Supply

supply voltage/frequency	AC 220 V, 50Hz
rated power consumption	24 W
standby power consumption	0.4 W

Weight and Dimensions

width	410 mm
height	170 mm
depth	190 mm
weight	4.6 kg (net)
