Kenwood MDX-01 User Manual

A/D keys
EEPROM Write
M30624MG-308FP
RELAY
POWER key
RESET
LED
Remote
key
LCD Back
Light
LCD CD
MD
DSP
u-COM
Control
KEY1-3
V.DET.
SENS
CLOSE
TUNER ON/OFF, SA CLK,
SA DATA
ST, SD,PLL DO
MD CE
SQSO
LCDSDA
LCDCS
LED0, LED1
BL0,BL1
REMOCON
RESET
RELAY
SCL
SDA
SCOR
CRXD CTXD
LCDRS
LCDSCL
LCDRES
SQCK
MD RST
CLS SW
CD POWER, LDC,HI SP. SCLK. CD CLK.XLAT.CD DATA.XRST
AC/BATTERY
CD Door
Control
TUNER PLL
IC
SYSTEM IC
LC75396NC
TUNER
SYSTEM IC
MDX-01/02
7
CIRCUIT DESCRIPTION
6. Microprocessor: M30624M-308FP(IC401)
6-1 Periphery Block Diagram
No. Key Display/Function
1. CD Error Rate
1 4 ¢ [CPLAY MODE]
2 Load the test disc(TGYS-1)
3 PLAY Display shows [CPLAY MID]
Access end
[c=xxxx a=yy] xxxx=C1 error (lower 20) yy=AIDP error
4 STOP [CPLAY MODE]
5 EJECT Unload disc.
2. MO Error Rate
No. Key Display/Function
1 4 ¢ [CPLAY MODE]
2 Load the recordable disc
3 PLAY Display shows [CPLAY MID]
Access end
[c=xxxx a=yy] xxxx=C1 error (lower 50) yy=AIDP error(00)
4 STOP [CPLAY MODE]
5 EJECT Unload disc.
No. Key Display/Function
1
4 ¢ Select [FBIAS ADJU]
2 Load the disc.
3 PLAY [a=xx yyyy/] point a
(xx=focus bias, yyyy=C1 error)
4
4 ¢ Adjust "yyyy" to 220 ✻
5 PLAY [b=xx yyyy/] point b
6
4 ¢ Adjust "yyyy" to 220 ✻
7 PLAY [C=xx yyyy/] point c
Check "yyyy" within 50
8 PLAY Display shows [aa bb cc(xx)] focus bias adjust
(aa= point a,bb=b,cc=c )
* Notes :
1. The relation between the C1 error and focus bias value
is shown in the figure below. Points "a" and "b" in the
figure are detected by the above adjustment. Focal
position "C" is automatically obtained from points "a"
and "b" by calculation.
2. The C1 error rate fluctuates. Therefore, perform the
adjustment according to the observed mean value.
5-8 Focus Bias Adjustment
Use the special disc(continuous recorded disc)
Focus bias value
C1 error
5-9 Error Rate Check
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299

Kenwood MDX-01 Specifications

Amplifier Section

maximum practical output	2 W + 2 W (EIAJ, 4 Ω)

Tuner Section

FM tuning frequency range	87.5 MHz ~ 108 MHz
AM tuning frequency range	531 kHz ~ 1, 602 kHz

CD Player Section

D/A conversion	1 Bit
sampling frequency	8 fs (352.8 kHz)
frequency response	20 Hz to 20, 000 Hz

MD Recorder Section

laser wave length	765 to 805 nm
laser power class	Class 3B
audio compression method	ATRAC

Speakers

enclosures	Bass-reflex type
speaker units	80 mm, cone type
reading method	Non-contact optical read (using a laser diode)

Power Supply

supply voltage/frequency	AC 220 V, 50Hz
rated power consumption	24 W
standby power consumption	0.4 W

Weight and Dimensions

width	410 mm
height	170 mm
depth	190 mm
weight	4.6 kg (net)
