Kenwood NX-5200 User Manual

MAKING A STATUS CALL
1
Select your desired zone and channel.
2
Press the key programmed as [Status] to enter Status mode.
Alternatively, press the key programmed as [Menu] to enter Status mode using the Menu
Mode.
3
Press the [J] and [K] keys to select the status ID you want to transmit.
4
Press the PTT switch or the [ ] key to initiate the Status call.
●
After the status call has been successfully received by the called unit, “Complete”
appears on the display.
34

Kenwood NX-5200 Specifications

General

IP Rating	IP67
Zones	128
GPS	Yes
Bluetooth	Yes
Voltage Range	7.5V DC ±20%
Operating Temperature	-30°C to +60°C
Frequency Range	136-174 MHz
Battery Life	14 hours (Digital mode)
Digital Protocol	NXDN, DMR
Display	LCD
