14
INSTALLING THE (OPTIONAL) ANTENNA
Screw the antenna into the connector
on the top of the transceiver by holding
the antenna at its base and turning it
clockwise until secure.
Optional
antenna
INSTALLING THE BELT CLIP
If necessary, attach the belt clip
using the two supplied M3 x 8 mm
binding screws.
Note:
• If the belt clip is not installed, its
mounting location may get hot
uring continuous transmission
or when left sitting in a hot
environment.
Belt clip
M3 x 8 mm
screws
Do not use glue which is designed to prevent screw loosening when
installing the belt clip, as it may cause damage to the transceiver.
Acrylic ester, which is contained in these glues, may crack the
transceiver’s back panel.
