Kenwood NX-5200K3 User Guide

15
INSTALLING THE CAP OVER THE UNIVERSAL
CONNECTOR
1 If you are not using an optional
speaker/ microphone or headset,
install the cap over the universal
connector.
2 Secure the cap in place using
the dressing screw.
INSTALLING THE (OPTIONAL) SPEAKER/ MICROPHONE
OR HEADSET
1 Insert the guide of the speaker/ microphone or headset
connector into the groove of the universal connector.
2 Secure the connector in place using the attached screw.
Optional speaker/
microphone
Note:
• When not using an optional speaker/ microphone or headset,
install the cap over the universal connector.
• The noise canceling function on KMC-54WD Speaker Microphone
works using the built-in DSP of the transceiver, and can only be used
with NX-5000 series Portable models.
Universal
connector cap
