4
TERMINAL DESCRIPTIONS
3.5 mm phone jack
No. Name Description Impedance I/O
1 GND Ground Ground −
2 EXTPTT External PTT Detection 47 k
Ω
I
3 MIC External MIC Input 1.8 k
Ω
I
4 EXTSP Internal Audio Output 32
Ω
O
5 Not used − − −
6 Not used − − −
7 Not used − − −
Micro USB jac
k (B type)
No. Name Description Impedance I/O
1 VBUS USB Detect 13 k
Ω
I
2 D- DATA High Impedance/ 44
Ω
I/O
3 D+ DATA High Impedance/ 44
Ω
I/O
4 ID NC − NC
5 GND Ground Ground −
RF EXPOSURE STATEMENT
This KENWOOD transceiver has been tested and complies with
general population/uncontrolled exposure limits in RSS-102 and
Safety
Code6.
The
followinglistprovidesyouwiththeinformationrequiredto
ensure that you are aware of RF exposure and of how to operate
this transceiver so that RF exposure limitations are not exceeded.
• While transmitting, always keep the antenna and the radio at least
3cm(13/16inches)fromyourbodyorface,aswellasfromany
bystanders.
• Do not transmit for more than 50% of the total transceiver use time.
• Use only the specified antenna for this transceiver.
Use only KENWOOD authorized accessories (antennas, battery
packs, belt clips, speaker/ microphones or headsets etc.): When
worn on the body, always place the radio in a KENWOOD
recommended clip or carrying case meant for this product. The use
of other than recommended or approved body- worn accessories
may result in RF exposure levels which exceed RF exposure limits.
