MODE CARRIER
MODULATION
ANT INPUT
FREQUENCY DEVIATION
FM 98MHz 1kHz STEREO 67.5kHz 7.5kHz(Pilot) 60dB
AM 1000(999)kHz 400Hz MONO 30% MOD 60dB
The DC voltage is an actual reading measured with a high
impedance type voltmeter as the AM/FM signal generator is
specified to the conditions as shown in the list below. The
measurement value may vary depending on the measuring
instruments used or on the product. The value shown in ( ) is
actual reading measured in the AM made.
CAUTION: For continued safety,
replace safety critical components only
with manufacturer's recommended
parts (refer to parts list). indicates
safety critical components. For
continued protection against risk of
fire, replace only with same type and
rating fuse(s). To reduce the risk of
electric shock, leakage-current or
resistance measurements shall be
carried out (exposed parts are
acceptably insulated from the supply
circuit) before the appliance is
returned to the customer.
The DC voltage is an actual reading
measured with a high impedance type
voltmeter with no signal input. The
measurement value may vary
depending on the measuring
instruments used or on the product.
R-A100(K) PCB/SD 2P 98.4.25 10:46 y[W 6
