INSTRUCTION MANUAL
© B62-0739-20 (K,E,T,M)
09 08 07 06 05 04 03 02
KENWOOD CORPORATION
144/440 MHz FM DUAL BANDER
144/430 MHz FM DUAL BANDER
TH-G71A
TH-G71A
144/430 MHz FM DUAL BANDER
TH-G71E

Table of Contents

Questions and Answers:

Kenwood TH-G71E Specifications

General IconGeneral
Frequency Range144-146 MHz / 430-440 MHz
ModulationFM
Current drain TX1.5A
Antenna impedance50 Ohms
TypeHandheld
Power Output5 W (VHF), 5 W (UHF)
Channel Spacing12.5 kHz, 25 kHz
Channel Step5kHz / 10kHz

Summary

Preparation Guide

Installing the NiCd Battery Pack

Step-by-step guide for attaching the NiCd battery pack.

Installing Alkaline Batteries

Instructions for inserting and securing alkaline batteries.

Operating Basics

Transmitting

Steps for initiating and conducting a transmission.

Scan Functions

VFO Scan

Scanning all frequencies within a selected band.

Memory Scan

Scanning through all memory channels with stored data.

Program Scan

Scanning within user-defined frequency ranges.

Priority Scan

Monitoring a favorite frequency while operating on another.

Continuous Tone Coded Squelch System (CTCSS)

Using CTCSS

Guide to activating and using CTCSS for selective calls.

Automatic Tone Frequency ID

Function to automatically identify incoming CTCSS tones.

Dual Tone Multi-Frequency (DTMF) Functions

Storing DTMF Numbers for Automatic Dialer

Storing numbers in dedicated DTMF memory channels.

Auxiliary Functions

Transceiver Lock

Prevents unauthorized changes to transceiver settings.

Maintenance Procedures

Charging the NiCd Battery Pack

Detailed steps for charging the NiCd battery pack.

Troubleshooting Guide

Table of common problems, causes, and corrective actions.

Equipment Installation and Connection

Connecting an External Power Source

Connects transceiver to external power sources.
