TK-260G/(N)/270G/(N)
36
ADJUSTMENT
Test Equipment Required for Alignment
Test Equipment Major Specifications
1. Standard Signal Generator Frequency Range
136 to 150MHz ((N)E2) 146 to 174MHz (E, (N)E).
(SSG) Modulation Frequency modulation and external modulation.
Output -127dBm/0.1µV to greater than -47dBm/1mV
2. Power Meter Input Impedance 50Ω.
Operation Frequency
136 to 150MHz ((N)E2) 146 to 174MHz (E, (N)E).
Measurement Range Vicinity of 10W
3. Deviation Meter Frequency Range
136 to 150MHz ((N)E2) 146 to 174MHz (E, (N)E).
4. Digital Volt Meter Measuring Range 10mV to 10V DC
(DVM) Input Impedance High input impedance for minimum circuit loading.
5. Oscilloscope DC through 30MHz.
6. High Sensitivity Frequency Range 10Hz to 1000MHz.
Frequency Counter Frequency Stability 0.2ppm or less.
7. Ammeter 5A.
8. AF Volt Meter Frequency Range 50Hz to 10kHz.
(AF VTVM) Voltage Range 1mV to 10V.
9. Audio Generator (AG) Frequency Range 50Hz to 5kHz or more.
Output 0 to 1V.
10. Distortion Meter Capability 3% or less at 1kHz.
Input Level 50mV to 10Vrms.
11. Spectrum Analyzer Measuring Range DC to 1GHz or more
12. Tracking Generator Center frequency 50kHz to 600MHz
Output Voltage 100mV or more
13. 8Ω Dummy Load Approx. 8Ω, 3W.
14. Regulated Power Supply 5V to 10V, approx. 3A
Useful if ammeter equipped.
