TK-2107/ TK-3107 OPERATION
Note: When the battery pack voltage becomes too low, transmission will
stop and the LED will blink red. See “Low Battery Warning” on page 12.
Switch ON the transceiver by
turning the Power switch/ Volume
control clockwise.
• A beep sounds.
Adjust the volume by pressing
and holding the Monitor key, then
rotating the Power switch/
Volume control.
Rotate the Channel selector to
select your desired channel.
• When you receive an appropriate
signal, you will hear audio from
the speaker.
To make a call, press and hold the
PTT switch, then speak into the
microphone using your normal
speaking voice.
• Hold the microphone approximately
1.5 inches (3 to 4 cm) from your lips.
Release the PTT switch to receive.
1
3
5
7
9
11
13
16
1
3
5
7
9
11
13
16
1
3
5
7
9
11
13
16
To Next Page
