Kenwood VR-509 User Manual

Notes
1. KENWOOD follows a policy of continuous advancements in development. For this reason specifications may be changed without notice.
2. The full performance may not be exhibited in an extremely cold location (under a water-freezing temperature).
AUDIO section
Rated power output during STEREO operation
100 watts per channel minimum RMS, both channels driven, at
8 Ω from 20 Hz to 20 kHz with no more than 0.7% total harmonic
distortion. (FTC)
Effective power output during SURROUND operation
FRONT (20-20kHz, 0.7% T.H.D. at 8 Ω one channel driven)
.............................................................................. 100 W + 100 W
CENTER (20-20kHz, 0.7% T.H.D. at 8 Ω one channel driven)
............................................................................................. 100 W
SURROUND (20-20kHz, 0.7% T.H.D. at 8 Ω one channel
driven) .................................................................. 100 W + 100 W
Total harmonic distortion ........................... 0.05% (1 kHz, 50W, 8 Ω)
Frequency response
CD ............................................. 10 Hz ~ 60 kHz, +0 dB, –3.0 dB
Signal to noise ratio (IHF’66)
PHONO (MM) ........................................................................ 75 dB
CD ......................................................................................... 91 dB
Input sensitivity / impedance
PHONO (MM) ......................................................... 2.5 mV / 27 kΩ
CD ......................................................................... 200 mV / 47 kΩ
MONITOR IN ........................................................ 200 mV / 47 kΩ
DVD/6CH INPUT .................................................. 200 mV / 47 kΩ
Output level / impedance
TAPE REC .............................................................. 200 mV / 1 kΩ
MONITOR OUT ...................................................... 200 mV / 1 kΩ
PRE OUT (SUBWOOFER) ...................................... 1.5 V / 2.2 kΩ
Tone control
BASS ................................................................ ±10 dB (at 70 Hz)
TREBLE .......................................................... ±10 dB (at 10 kHz)
DIGITAL AUDIO section
Sampling frequency ...................... 32 kHz, 44.1 kHz, 48 kHz, 96kHz
Input level / impedance / wave length
Optical ............................. (-15 dBm ~ -21 dBm), 660 nm ±30nm
Coaxial ................................................................. 0.5 Vp-p / 75 Ω
VIDEO section
VIDEO inputs / outputs
VIDEO (composite) ............................................ 1 Vp-p / 75 Ω
S VIDEO (luminance signal) ................................ 1 Vp-p / 75 Ω
(chrominance signal) ..................... 0.286 Vp-p / 75 Ω
COMPONENT VIDEO (luminance signal) ............. 1 Vp-p / 75 Ω
(C
B
/C
R
-signal) ........ +/– 0.324 Vp-p / 75 Ω
FM tuner section
Tuning frequency range ................................... 87.5 MHz ~ 108 MHz
Usable sensitivity (MONO)
................ 1.3 µV (75 Ω)/ 13.2 dBf (75 kHz DEV., SINAD 30 dB)
50dB quieting sensitivity
STEREO ................................................... 28 µV (75 Ω)/ 40.2 dBf
Total harmonic distortion (1 kHz)
MONO ............................................................ 0.5% (65 dBf input)
STEREO ........................................................ 0.7% (65 dBf input)
Signal to noise ratio (1 kHz, 75 kHz DEV.)
MONO .......................................................... 75 dB (65 dBf input)
STEREO ...................................................... 68 dB (65 dBf input)
Stereo separation (1 kHz) ..........................................................40 dB
Selectivity (±400 kHz) ................................................................. 70 dB
Frequency response ................. (30 Hz ~ 15kHz), +0.5 dB, –3.0 dB
AM tuner section
Tuning frequency range
10 kHz step ................................................. 530 kHz ~ 1,700 kHz
Usable sensitivity ................................................. 16 µV / (600 µV/m)
Signal to noise ratio (30% mod. 1 mV input) ........................... 50 dB
GENERAL
Power consumption .................................................................... 2.6 A
AC outlet
SWITCHED ....................................... (total 150 W, 1.25 A max.)
Dimensions ..................................................... W : 440 mm (17-5/16")
H : 144 mm (5-11/16")
D : 399 mm(15-11/16")
Weight (Net) ................................................................ 8.8 kg (19.4 lb)
Specifications
Caution : Read this page carefully to ensure safe
operation.
For your records
Record the serial number, found on the back of the unit, in the spaces
designated on the warranty card, and in the space provided below. Refer
to the model and serial numbers whenever you call upon your dealer for
information or service on this product.
Model __________________ Serial Number ________________________
*509/40-48/EN 3/15/01, 2:17 PM48

Kenwood VR-509 Specifications

Audio Specifications

rated power output during stereo operation	100 watts per channel minimum RMS, both channels driven, at 8 Ω from 20 Hz to 20 kHz with no more than 0.7% total harmonic distortion
effective power output during surround operation front	100 W + 100 W
effective power output during surround operation center	100 W
effective power output during surround operation surround	100 W + 100 W
total harmonic distortion	0.05% (1 kHz, 50W, 8 Ω)

Video Specifications

video inputs/outputs composite	1 Vp-p / 75 Ω
s video luminance signal	1 Vp-p / 75 Ω
s video chrominance signal	0.286 Vp-p / 75 Ω
component video luminance signal	1 Vp-p / 75 Ω
component video CB/CR signal	+/– 0.324 Vp-p / 75 Ω

FM Tuner Specifications

tuning frequency range	87.5 MHz ~ 108 MHz
usable sensitivity mono	1.3 µV (75 Ω)/ 13.2 dBf (75 kHz DEV., SINAD 30 dB)
50dB quieting sensitivity stereo	28 µV (75 Ω)/ 40.2 dBf
total harmonic distortion mono	0.5% (65 dBf input)
total harmonic distortion stereo	0.7% (65 dBf input)
signal to noise ratio mono	75 dB (65 dBf input)
signal to noise ratio stereo	68 dB (65 dBf input)
stereo separation	40 dB
selectivity	70 dB (±400 kHz)
frequency response	30 Hz ~ 15kHz, +0.5 dB, –3.0 dB

AM Tuner Specifications

tuning frequency range	530 kHz ~ 1, 700 kHz (10 kHz step)
usable sensitivity	16 µV / (600 µV/m)
signal to noise ratio	50 dB (30% mod. 1 mV input)

General Specifications

power consumption	2.6 A
dimensions width	440 mm (17-5/16")
dimensions height	144 mm (5-11/16")
dimensions depth	399 mm(15-11/16")
weight	8.8 kg (19.4 lb)

Digital Audio Specifications

sampling frequency	32 kHz, 44.1 kHz, 48 kHz, 96kHz
input level/impedance/wave length optical	(-15 dBm ~ -21 dBm), 660 nm ±30nm
input level/impedance coaxial	0.5 Vp-p / 75 Ω
