Kenyon Mediterranean - Installing the Cooktop

STEP #4
Installing the Cooktop
There are two mounting brackets supplied with the glass ceramic cooktop. These brackets
aredesignedtoholdthecooktoprmlyinplace.Thecooktopdoesnothaveametalframe
and should be bedded to the countertop using a soft bedding compound that will prevent
damage if later removal for service is necessary. We recommend a very small bead of
silicone sealant.
Attach the two mounting brackets supplied with the KENYON cooktop (as shown) to the
inside vertical surface of the cutout. The brackets are to be mounted on opposing sides. If
your counter material is granite you will need to glue two wood strips underneath the
countertoacceptthemountingbrackets.Centerthebracketintheopening,ushwiththe
countertop and secure with long self-tapping screws that are provided. Position the
cooktopinthecutoutopeningandpressrmlyonallsidestosealtheframeintothe
bedding compound. Secure the cooktop to the brackets from underneath with the small
sheet metal screws that are supplied.
BE CAREFUL NOT TO OVERTIGHTEN THE SCREWS.
KENYON COOKTOP
# 8 X 1/4" SCREW
# 6 X 1 1/4" S/S SCREW
MOUNTING BRACKET
COUNTER SURFACE
5
