6.2 Mode „parts counting“
Set mode „parts counting“ with
F
and
TARE
on
„1 Set 2“
,, see point 10 „General
programmations
Confirm with
S
.
Press
F
and release it when
„U SEt“
appears.
Now flashing indication
on.....PC %
Select the required reference number
→
5
→
10
→
30
→
100 pieces by repeatedly
pressing
TARE
.
Important!
The higher the reference number,
the exacter the parts counting.
Place so much parts on the weighing plate as the set reference number requires.
Confirm with F, the memorising will need a short time. Now this reference number
appears.
When the display is flashing an optimisation will be possible. At the same time two
triangles appear at the left side.
Now double or max. triple approximately the quantity. The following optimisation is
running automatically. It is finished when a beep comes out. No confirm required.
When the display is still flashing and shows
Add
, at the right side a new optimi-
Sation should be performed by doubling or max. tripling the quantity, same procedure
as above.
When
Sub PC 5
, appears remove so much parts from the weighing plate until
this display will disappear.
Press
F
when the optimisation should be terminated.
Now the balance is ready for counting and will count all parts being on the weighing
plate.
Indication of the unit weight of one part as well as the total weight in
„g“
of all parts on
the weighing plate to be counted by repeated pressing of
F
.
Now parts counting by over-writing the reference number. Press
F
and release it when
U SEt
appears.
Minimum weight for counting parts see table „Technical data“
L - Err
Appears when the unit weight of the parts is below the minimum weight
as specified.
