FTx/ITx-SH-e-0720 21
Item Qty. Description Order No.
1 1 weighing pan 240 x 350 mm 21203072
2 4 rubber cushions
1)
21203073
3 2 countersunk Torx screw M6 x 30 *
4 1 pan support plate 240 x 350 mm –
5 1 housing, large platform –
6 1 keypad overlay Chap. 3.3 – 3.4
7 1 mounting plate and display unit (digital PCB with LCD and backlighting unit) Chap. 3.3 – 3.4
8 2 EMC clamp 21203480
* included in the small parts set (Chapter 4.5)
1)
New rubber cushions have a hole in the surface to assist with assembly. A pin can be used to insert the cushion into the
corresponding drilled hole in the load plate support
