Item Qty. Description Order No.

1 1 base plate with seal attached 21255118

2 4 rubber foot 00200068

3 8 countersunk screw M4 x 12 Torx T20 *

4 4 fillister head screw M5 x 12 *

5 1 PCB for NiMH storage battery charger circuit 22011451

6 2 fastening clamp for charging circuit board *

7 1 connecting cable charging circuit – analog board 21203233

8 1 battery cable –

9 1 battery 14.4V NiMH (always order together with item 10) 22011350

10 2 adhesive tape for battery 21255260

11 1 bench AC adapter 8VA (always order together with adhesive tape order no. 21203184):

EURO version 22011363

USA version 22011364

UK version 22011365

JAPAN version 22011366

Australian version 22011367

external power supply unit (battery charger) for operation with a storage battery

(without power cable) 22011300

socket for external power supply unit 22011311

12 1 seal for back panel OptionPac 21255013

13 1 back panel without openings 21255003

14 1 analog interface option board only KMS/KMT-TM 21203383

15 4 tapping screw M3 x 6 –

16 1 EPROM with interface software for analog option (KMS/KMT-TM only) 22013444

17 1 cable for analog option (KMS/KMT-TM only) 21203604

18 1 seal (between OptionPac and terminal) 21255011

5 fillister head screw M4 x 8 Torx T20 *

1 countersunk screw M4 x 10 Torx T20 *

* included in the small parts set (Chapter 4.5)
