K4C COMPACT-MULTI – INSTALLATION/OPERATION MANUAL
K4C Compact-multi Feb-06
14
OPENING HEIGHTS (from floor)
Burner c/l 24” (610 mm)
Smoke pipe c/l 37” (940 mm)
SMOKE/VENT PIPE
5” Chimney
4” Direct Vent
CLEANOUTS
Front covers, Burner opening, Front/Rear cover plate
AIR FILTERS Pleated 16” x 20” x 1”
FUEL not heavier than No. 2 furnace oil.
ELECTRICAL - 120 Volts, 60 Hz
Canada Less than 12 amps.
US 13.3 amp, circuit protection 20 amps.
This furnace has been tested to, and meets the requirements of B212-93 Seasonal
Energy Utilization Efficiencies of Oil-Fired Furnaces & Boilers & the Energy-Efficient
Appliances Act of 1991.
Certified for use with Type “L” & Type ”A” vent – maximum flue gas temperature 575°F.
Certified for use with Kerr Direct Vent.
Certified for use with Kerr KPV-SS1C through-the-wall mechanical vent system.
10.0 TROUBLE SHOOTING GUIDE
Furnace will not start
Tripped blocked vent switch Clear vent, reset switch.
Tripped breaker Determine cause, reset breaker.
No oil Check tank for leaks and call oil supplier.
Oil burner keeps turning off
Dirty air filter Change air filter.
Restricted air supply/return Check all air return/supply registers.
Limit control Check ductwork for blockage.
Motor over heating Check motor speed correct for nozzle on furnace
label settings.
Dirty nozzle Call technician to replace nozzle.
Sooty flame
Wrong pump pressure Increase or decrease pressure to correct setting.
Dirty nozzle Replace nozzle.
Improper burner setting See “BURNER SPECIFICATIONS”.
Barometric draft wrong Adjust barometric regulator for -0.04” wc draft
pressure at breech.
