11
ENGLISH
PROGRAMMING WORK AND SELF-LEARNING PAUSES
1. Bring the automation gate to approximately half its stroke.
2. Press the PROG button and keep it pressed for 3 seconds. The blinker or LED L1 will go on and remain on steady
warning that you have entered the programming procedure.
3. Press the P/P button to close the Gate all the way to the end of its stroke. After 2 second it will invert direction to
opening and the gate will be opened all the way (the entire learning procedure is performed in slow motion). In case li-
mit switches are not detected by the control unit, we advise users to turn both magnets by 180° on the horizontal metal
brackets on which magnets are xed.
4. The rst maneuver performed by the control unit is closing. This makes it possible for the unit to determine whether
the motor is turning in the proper direction. If not, and the unit does not close. In this case run a RESET by touching
the two Pins marked RESET with the tip of a screwdriver. The control unit will immediately block the operation, thus
enabling you to invert polarity of the motor cables. Then repeat programming starting from point 2.
5. The gate opens all the way to the limit switch.
6. Start the timing count for automatic closing and let the desired time elapse.
7. Press the P/P button once more or press the remote control button.
8. The gate starts the closing maneuver and continues until it has reached the fully closed limit switch.
9. The control unit automatically exits the programming procedure and Led LD1 goes off.
You can pre-calibrate or check the magnetic limit switches during programming. PROCEDURE:
- Release the gate by triggering the motor, the gate will move freely.
- Enter programming mode by pressing the PROG button and keeping it pressed for 5 seconds.
- Manually move the gate. When it nears the limit switch the blinker and led DL1 will ash.
- Make the necessary adjustments.
- Lock the motor once more and proceed with point 3 of the self-learning procedure.
To ensure that the gate stops precisely when the limit switch is detected, we suggest activating maximum slowdown
(Dip 5 = ON) and minimum slowdown (Dip 1 = ON).
PEDESTRIAN OPENING PROGRAMMING
With default programming the Pedestrian command automatically runs a partial opening of 20% of the total stroke
acquired with Dip 6 = OFF.
To increase this opening percentage to 40% of total opening, set Dip 6= On.
DIP No. FUNCTION OFF ON
1
Speed during
slowdown
High speed Low speed
2 Automatic Closing OFF ON
3 P/P Control Function
An Open pulse A Clo-
se pulse
An Open pulse / A Stop pulse / A Close pulse
4 Shared Accept P/P pulse
Upon opening rejects inversion or stop com-
mand through the P/P inlet – In closing accepts
inversion or Stop command
5 Percentage Slowdown
10% of the total run
saved
30% of the total run saved
6
Percentage Pede-
strian opening
20% partial opening 40% partial opening
7 Blinker / Courtesy light
Bistable opening for
Blinker connection
Monostable output timed at 90 sec from last
operation
8 Phototest
Phototest NOT ena-
bled
Phototest ENABLED when Photo is on in FCH
closing
