MODELS AND SPECIFICATIONS
TECHNICAL DATA
6
3
Electromechanical irreversible gear motor for
sliding gates up to 350kg.
230 Vca (24Vdc motor) feeding
Electronic clutch
Built in encoder, central unit and radio.
Complete with magnetic limit switch
Fixing plate and fixing screws
Pinion to vertical M4 toothed rack
FEEDING
FREQUENCY
RATED ABSORBED POWER
MOTOR ABSORPTION
CONDENSER
PROTECTIVE DEGREE
COUPLE
SPEED
THRUST FORCE
MAX GATE WEIGHT
THERMOPROTECTION
INSULATION CLASS
TEMPORARY SERVICE
RUNNING TEMPERATURE
WEIGHT
900SC-30C
230 Vac
50/60Hz
120 W
1A
-
Ip56
25 NM
0,22 M/S
340 N
300 KG
-
I
60%
-20°/+50°C
7,5 KG
