4 - PRODUCT INSTALLATION
MOTOR / POWER SUPPLY CONNECTIONS
Power supply connection terminal board
11 Motor close
12 Motor open
13 Motor common
14 Power supply 230 Vac 50-60 Hz
15 Power supply 230 Vac 50-60 Hz
4.1 - Electrical connections
WARNING - Before making the connections, ensure that the control unit is not powered up.
14 230 Vac 15 230 Vac
7 24 Vac 8 24 Vac
3 PH1 2 SHIELD 1 SIGNAL 4 STOP 6 SS 9 CLOSE
12 OPEN
10 OPEN
11 CLOSE
5 COM
13 COM
M
2
1
GND
_
12/24
AC/DC
3
4
1
2
TX
RX
PH1
GND
_
12/24
AC/DC
COM
OUT
NC
16
17
SELECTION
MODE
MEMORY
A.R
W.T
CD.
MAX
MIN
FUSE
6,3 A
J1
J2
J3
J4
J5
