521 East 3
rd
Street Mt. Vernon, NY 10553 • www.keydigital.com
Rev 0 – May 2020
14
Dimensions and Mounting
DIMENSIONS
Length = 6.93in / 176mm, Width = 6.14in / 156mm, Height = 6.69in / 170mm
Weight = 2.2lbs / 1.0kg
MOUNTING
Tripod style mounting bolt: 1/4-20 UNC screw (included)
NOTE: Do not install on drop ceiling / plasterboard.
Wall Mounting:
