Keyscan Technical Guide (PC109x - 04.12)

Figure 65 – Single ACU Communication - CB-485M/MC33H

to Com Port

PC with

Communication

Manager

- RS-232 Modem Cable

- Control Board

- CB-485M

- MC33H Modem

- PC (requires serial port)

- Dedicated Analog Phone Line

GND

CB-485M

LED

BRN WHT GRN WHT BRN WHTGRNWHT BLUWHT

RS485 IN RS485 OUT M

+-+-+-+-

Jumper ON J1

MC33H

Modem

RJ 11 Terminal

- connect to

analog phone

line

12 VDC

Adaptor

Modem

Chip

RJ 11 Terminal

- connect to

analog phone line

RS-232

Modem

Cable

Current Draw - 360 mA

Jumpers ON Run

DCD

LED

RING

LED

MC33H - DCE

Control Board

(PC 109x)

Common

AUX Inputs - E

2322

2120191817

CPB/CB MODULE

(COM4)

Parts List

Connect CB-485M ribbon cable to

CPB/CB MODULE on control board.

Jumper ON J16-G to activate

CPB/CB MODULE (H1).

SYSTEM CONFIG.

J16 - H

GABCDEF

Run

Program

ECM/GCM MODULE

(COM2 & COM3)

KI-00168E-07-11
