Theory of Operation 5
Keysight 34970A/34972A Service Guide 131
Memory
Unless otherwise noted, components in this discussion are located on the A1
circuit assembly (34970-66501).
The main controller, U205, uses 512 Kbytes of ROM and 544 Kbytes of RAM. ASIC
U209 provides the memory mapping that allows access to this large memory
space. The memory map as seen by the main controller is as follows:
The memory is organized with a 16-bit data bus (AD(15:0)) and a 19-bit address
bus (MA(19:1)). The memory address is produced by U209 latching the address
present on AD(15:0) when U205 asserts ALE_FLT. Reads of memory are always
16-bits wide (there is a single RD_N signal). Writes, however, can be byte-wide
and therefore U209 produces both a high-byte write strobe, MWRH_N, and a
low-byte write strobe, MWRL_N. These write signals are based on the latched
0-bit of the address and the BHE_N signal produced by the main controller, U205.
The ROM memory consists of a single, 256Kx16 device, U401. The RAM memory
consists of five devices: U402, U403, U404, U405, and U410. A uniform, 256Kx16,
memory block is formed by the four 128Kx8 devices, U402 through U405. A
separate, 32Kx8 block is formed by U410 and is available through special
programming of U209.
Address Maps to
0100H thru 1FBFH 00100H thru 01FBFH in RAM for data fetches
0100H thru 1FBFH 00100H thru 01FBFH in ROM for instrument fetches
1FC0H thru 1FDFH registers in U209
2000H thru 5FFFH 02000H thru 05FFFH in ROM
6000H thru 7FFFH 06000H thru 07FFFH in RAM for data fetches
6000H thru 7FFFH 06000H thru 07FFFH in ROM for instrument fetches
8000H thru FFFFH any selected 32 Kbyte page of ROM or RAM
