Keysight Technologies 53220A - Figure 2-1 the Front Panel at a Glance

Service 2
Keysight 53210A/53220A/53230A Assembly Level Service Guide 101
Figure 2-1 The front panel at a glance
1 USB Port
2 On / Standby Switch
3 Menu Softkeys
4 Back / Local Key
5 Channel Input Connectors
6 Channel Input Keys
7 L-R / Cursor Keys
8 Knob
9 System Keys
10 View Keys
11 Measure Keys
8
4
911
3
2
1 7
10
6
5
