1 Performance Tests
98 Keysight 53210A/53220A/53230A Assembly Level Service Guide
7b
Option 106
Option 150
53230A
Pulse Burst
Frequency
(6 GHz)
Wide Pulse Wid th
(13 uSec)
5.999 954 000 GHz
Record: Mean
__________________
Record: Std Dev
_____________________
6.000 046 000 GHz
18.500 kHz
7c
(Q)
Option 115
Option 150
53230A
Pulse Burst
Frequency
(1.35 GHz)
Narrow Pulse Wid th
(400 nSec)
1.348 865 000 GHz
Record: Mean
__________________
Record: Std Dev
_____________________
1.351 350 000 GHz
338 kHz
7d
Option 115
Option 150
53230A
Pulse Burst
Frequency
(1.35 GHz)
Wide Pulse Wid th
(13 uSec)
1.349 979 200 GHz
Record: Mean
__________________
Record: Std Dev
_____________________
1.350 020 800 GHz
7.79 kHz
Complete performance tests
Test
number
Test description Minimum Actual reading Maximum
