2 Verification and Adjustments
68 Keysight E36200 Series Service Guide
Low range current readback accuracy
Step Front panel SCPI
6 Set the instrument settings as
described in Table 2-7.
VOLT 60, (@<channel>); CURR
0.05, (@<channel>)
This is an example for the E36234A,
60 V, 50 mA output.
7 Enable the output by pressing the
On key for the selected output.
OUTP ON, (@<channel>)
8 Record the current measured by the
DMM and current returned by the
SCPI MEAS:CURR?, (@channel)
command query via the Keysight
Connection Expert in the “Test
Record Forms” on page 74, and
verify whether it is within the limits
calculated.
MEAS:CURR?, (@<channel>)
This is an example for the E36234A,
60 V, 50 mA output.
Table 2-7 Low range current readback accuracy instrument settings
Model
DUT settings Readback accuracy
Voltage (V) Current (A) Lower limit Upper limit
E36231A/E36233A 30 0.1 –410 μA410 μA
E36232A/E36234A 60 0.05 –205 μA –205 μA
