Keysight FieldFox Handheld Analyzers Service Guide 103
Replaceable Parts
Replaceable Parts Listings
Miscellaneous Parts
Description Model or Part
Number
Repair and Re-assembly Kit
IMPORTANT
This kit is required each time the FieldFox case is opened for any reason.
The kit includes the following items, some or all of which are necessary to re-assemble the
internal assemblies and the case, depending upon the depth of the repair.
Repair and Re-assembly Kit for N991xA, N992xA, N993xA
Includes the following items:
Screw, machine, 90-deg flat head, Torx T10, M3 x 0.5, 8mm; qty 4
Screw, machine, 90-deg flat head, Torx T10, M3 x 0.5, 6 mm; qty 17
Screw, machine w/patch lock, pan head, Torx T8, M2.5 x 0.45, 6 mm; qty 4
Screw, machine w/crest cup washer, pan head, Torx T10, M3.0 x 0.5, 8 mm; qty 4
Screw, machine, 90-deg flat head, Torx T10, M3 x 0.5, 14 mm; qty 6
Screw, machine, button head, Torx T8, M3 x 0.5, 8 mm; qty 4
Screw, machine w/flat washer, pan head, Torx T10, M3 x 0.5, 35 mm; qty 6
Rectangular Laser Address Label
O-STRIP RFI Hollow 0.060 in OD, 0.020 in ID; qty 1
Tape, 1/4-inch x 1-inch, for LCD ribbon cable; qty 4
Gasket, Blank Panel, qty 1
Gasket, I/O Panel, qty 1
Cover, hinge
N9927-60130
0515-1035
0515-1946
0515-1940
0515-0372
0515-2349
0515-2217
0515-5153
7121-8321
8160-1725
N9912-20043
N9912-40002
N9912-40003
W1312-40068
Repair and Re-assembly Kit for N995xA, N996xA
Includes the following items:
Screw, machine, 90-deg flat head, Torx T10, M3 x 0.5, 6 mm; qty 6
Screw, machine w/flat washer, pan head, Torx T10, M3 x 0.5, 35 mm; qty 6
Screw, machine, 90-deg flat head, Torx T10, M3 x 0.5, 14 mm; qty 8
Screw, machine, 90-deg-flat head, TORX-T10, M3 x 0.5, 5mm; qty 6
Black Protective Cap, .24-ID .277-OD; qty 2
Rectangular Laser Address Label; qty 1
Tape, 1/4-inch x 1-inch, for LCD ribbon cable; qty 4
Bolt, M1.6 SHC tall head; qty 6
Nut Ring, test port; qty 2
Overlay, screw cap; qty 6
N9950-60130
0515-1946
0515-5153
0515-6119
0515-6120
1401-0245
7121-8321
N9912-20043
N9950-20047
N9950-40006
N9950-80012
Ferrite Cores
Kit containing ferrite cores for use on external LAN cable and headphones cable. N9927-60028
(N991xA, N992xA,
N993xA only)
Service Tools
