Keysight FieldFox Handheld Analyzers Service Guide 95
Replaceable Parts
Replaceable Parts Listings
Measurement Group
Refer to Figure 6-3 for part locations.
Each time the FieldFox case is opened for any reason, you must order a “Repair
and Re-assembly Kit”
. See “Miscellaneous Parts” on page 103.
Reference
Designator
Part Number Qty Description
Replacement Assemblies
A4 RF
Assembly
N9927-60111 N9918A
N9928A
N9938A
1
RF Assembly—Includes:
A4 RF board
Cable W1, semi-rigid, RF OUT (NA port)
Cable W2, semi-rigid, RF IN (SA port)
O-Ring gasket, 8160-0963, qty 2 (8)
Adapter coaxial straight,
female Type-N to female 3.5 mm, qty 2 (9)
Insulator, qty 2 (10)
EMI ring, N9927-20064, gty 2 (11)
Shield, top, RF (19)
Shield, bottom, RF (21)
Screw, 26 places (22)
N9927-60200 N9913A
N9927-60201 N9914A
N9915A
N9925A
N9935A
N9927-60202 N9916A
N9917A
N9926A
N9927A
N9936A
N9937A
A4 RF
Assembly
N9950-60100 N995xA
N996xA
RF Assembly—Includes:
A4 RF board
2.4 mm Right Angle Connector, qty 2
Jam Nut, qty 4
Restrainer, qty 2
O-Ring gasket, qty 2 (8)
Shield, top, RF
Shield, bottom, RF
Screw, 28 places
SMP Bullet, qty 5
A5 System
Board
Assembly
N9927-60112
1
N991xA
N992xA
N993xA
1 System Board Assembly—Includes:
A5 system board, N9927-63002
Screw, 19 places, 0515-5511 (13)
Screw, 2 places, 0515-0430 (14)
Screw, 4 places, 0515-1940 (18)
A5 System
Board
Assembly
N9927-60150
2
N991xA
3
N992xA
N993xA
N995xA
N996xA
1 System Board Assembly—Includes:
A5 Pre-Programmed system board, N9927-60212
Screw, 19 places, 0515-5511 (13)
Screw, 2 places, 0515-0430 (14)
Screw, 4 places, 0515-1940 (18)
