96 Keysight FieldFox Handheld Analyzers Service Guide
Replaceable Parts
Replaceable Parts Listings
6-
RF
Top Panel
Assembly
N9927-60115 N991xA
N992xA
N993xA
1 RF Top Panel Assembly—Includes:
Connector cover (tethered cap), for Type-N connector, qty 2 (1)
Connector cover, for SMA connector (W3 & W4), 1401-0245,
qty 2
Screw, 0515-2349, 6 places (2)
Overlay, RF (5)
Panel, RF, machined, N9927-20013 (6)
Gasket, RF (7)
N9950-60115 N995xA
N996xA
1 RF Top Panel Assembly—Includes:
Connector cover (tethered cap), for 2.4 mm connector, qty 2 (1)
Screw, 0515-2349, 8 places (2)
Overlay, RF (5)
Panel, RF, machined (6)
Gasket, RF (7)
Separately Replaceable Individual Parts and Assemblies
A6 1150-8023 N991xA
N992xA
N993xA
1 SOM Board, 532 MHz processor, 128 MB-SDRAM
N9927-60100
N991xA
3
N992xA
N993xA
N995xA
N996xA
1 Pre-programmed CPU Board (CPU2)
A7 N9927-60121 1 RTC Battery Board Assembly
W1 N9927-20028 1 Cable, semi-rigid, Port 1 / RF Output
(N991xA, N992xA, N993xA only)
W2 N9927-20029 1 Cable, semi-rigid, Port 2 / SA RF Input
(N991xA, N992xA, N993xA only)
W3 8121-2029 1 Cable, SMA-MCX, Ref In/Trig In, incl. nut (3) and washer (4)
W4 8121-2029 1 Cable, SMA-MCX, GPS Ant, incl. nut (3) and washer (4)
W17 N9927-60010 1 Cable, RTC Battery board
(1) W1312-40069 2 Connector cover (tethered cap), for Type-N connector
N9927-40013 2 Connector cover (tethered cap), for 3.5 mm connector
(7) N9912-40004 2 Gasket
(8) 8160-0963 2 O-Ring gasket
Reference
Designator
Part Number Qty Description
