2-2 Keysight M937xA PXIe Service Guide
Tests, Adjustments, and Troubleshooting
Information in This Chapter
2-
Non-Standards Compliant Verification The Non-Standards Compliant process of verifying your network
analyzer.
Preliminary Checks Performing the Operator’s Check.
Checking your test cables.
NOTE Perform these checks before performing system verification.
System Verification What the system verification does.
How to perform the verification test.
How to interpret the results.
Performance Tests
a
A brief summary of each performance test:
-Source Power Accuracy
-Source Maximum Power Output Test
-Source Power Linearity Test
-Frequency Accuracy Test
-Trace Noise Test
-Receiver Compression Test
-Noise Floor Test
-Calibration Coefficients Test
-Dynamic Accuracy Test
Adjustments
b
Setups and procedures for adjusting your network analyzer:
-10 MHz Frequency Reference Adjustment
-Source Adjustment
-Receiver Adjustment
Troubleshooting A list of troubleshooting suggestions.
a. These performance tests are included in the analyzer’s firmware for Options 897 or 898.
b. These adjustments are included in the analyzer’s firmware on all models and options.
