3-2 Keysight M937xA PXIe Service Guide
Replaceable Parts and Connector Replacement Procedure
Replaceable Parts
3-
Replaceable Parts
The following table is a list of semi-rigid cables that are available for purchase.
For purchasing information, refer to “Contacting Keysight” on page 1-3.
The following table is a list of Service Kits that are available for purchase. For
purchasing information, refer to “Contacting Keysight” on page 1-3.
Cable Description Connector Type Qty Part Number
RF, LO jumper cable
(module LO Out port to adjacent
module LO In port)
SMA 1 M9370-20006
SMB trigger cable
(module Trig Out port to adjacent
module Trig In port)
SMB 1 M9370-20018
SMB reference jumper (module
Ref Out port to adjacent module
Ref In port)
SMB 1 M9370-20019
Service Kit Description Service Kit Model or
Option Number
Service Kit
Contents
Multiport Cable Kit Y1242A RF, LO jumper cable, qty 1
SMB trigger jumper cable, qty 1
SMB reference jumper cable, qty 1
Tool Kit for SMA and
SMB Connectors
Y1281A 5/16 inch socket adapter for 50 ohm loads
SMB cable removal tool
Connector
Replacement Kits
Y1283A, Option 101 SMA LO port connector, qty 2
Nut for connector, qty 2
Y1283A, Option 102 3.5 mm test port connector, qty 2
Nut for connector, qty 2
Y1283A, Option 103
SMA LO port connector, qty 2
Nut for SMA connector, qty 2
3.5 mm test port connector, qty 2
Nut for 3.5 mm connector, qty 2
“Spark plug” adapter
Torque wrench (for “spark plug” adapter)
