05 | Keysight | 34970A Data Acquisition/Switch Unit Family - Technical Overview
www.keysight.com/find/ 34970A
Unequaled ease of use
From the simplified configuration to the graphical Web interface
in the 34972A, we put in extra time and energy so you don’t have
to� Simple things like on-module screw-terminal connectors,
built-in thermocouple reference junctions, well-organized user
documentation full of examples and hints, and a standard Getting
Started kit that will have you making measurements in just a few
minutes all add up to increased productivity, whether you use the
instrument every day or only now and then�
Custom configurations that grow with you
Three module slots and eight switch/control modules allow you
to customize the 34970A/34972A to meet your unique require-
ments� Buy only what you need—and add more modules later as
your application grows�
34970A and 34972A are compatible
The 34972A LXI Data Acquisition/Switch Unit is an LXI version
of the 34970A� It replaces the GPIB and RS-232 interfaces
with modern connectivity for a direct connection to your PC or
Laptop�
The 8 plug-in modules can be used with either unit—so all the
measurements and wiring are compatible� The 34972A can be
easily integrated into an existing test program with a simple
change to the instrument address� Since the 34972A code is a
superset of the 34970A code, once the instrument address is
changed, the test program will run as normal�
Example:
Change:
Set inst1�IO = ioMgr�Open(“GPIB0::9::INSTR”)
To:
Set inst1�IO = ioMgr�Open(“TCPIP0::156�140�77�230::inst0::
INSTR”)
34970A 34972A
Support 8 plug-in modules
● ●
LabView drivers
● ●
IVI-C, IVI-COM drivers
● ●
BenchLink Data Logger
● ●
Optional BenchLink Data Logger Pro
● ●
Graphical Web interface
●
Gigabit LAN
●
USB 2.0
●
USB memory port
●
GPIB
●
RS-232
●

Keysight 34970A Specifications

General

Maximum Voltage	300 V
Maximum Current	1 A
Relay Type	Electromechanical
Type	Data Acquisition/Switch Unit
Slots	3
Connectivity	GPIB, RS-232
DC Voltage Range	100 mV to 300 V
AC Voltage Range	100 mV to 300 V
Resistance Range	100 Ω to 100 MΩ
Switch Type	Multiplexer, Matrix, General Purpose
Voltage Measurement Range	100 mV to 300 V
Temperature Measurement	Thermocouple, RTD, Thermistor
Switching Speed	60 channels/sec
DC Current Range	1 mA to 1 A
AC Current Range	1 mA to 1 A
Frequency Range	3 Hz to 300 kHz
Scan Rate	Up to 250 channels/sec
Current Measurement Range	1 µA to 1 A
Resistance Measurement Range	100 mΩ to 100 MΩ
