Keysight CX3322A Quick Operation Guide

Keysight Technologies
CX3300 Current Waveform Analyzer
Quick Operation Guide
How to change the current range
1. Click on the Channel summary to open the Channel mini dialog box.
2. Un-check “Auto”.
3. Select the “Range”.
Note:
- If “Auto” is enabled, a suitable range is selected automatically by the vertical
scale setting controlled by the Vertical scale control knob.
- The measurement bandwidth and the input resistor are automatically
changed by changing the range.
1
3
2
Click
16
