Keysight CX3322A - How to Apply a Measurement Function

1. Apply a Measurement Function (“+width” in this case)
1-1. Click the “Measurement” icon on the Tool Palette.
1-2. Drag and drop the “+width” icon onto the target. The color of the
icon shows the target waveform.
Keysight Technologies
CX3300 Current Waveform Analyzer
Quick Operation Guide
How to apply a Measurement Function
1-1
Measurement Stats window
Tool Palette
1-2
32
