Keysight CX3322A Quick Operation Guide

Keysight Technologies
CX3300 Current Waveform Analyzer
Quick Operation Guide
How to change the 14-bit or 16-bit resolution.
a
Change a 14-bit (high speed mode) or a 16-bit (high resolution mode) using the
[High Reso] key.
Indicator on Horizontal Summary
(none) : 14-bit (high speed mode)
“HR” : 16-bit (high resolution mode)
Note:
The maximum sampling rate and bandwidth is automatically changed by the mode.
Resolution Max. Sampling Max. Bandwidth
14-bit (high speed mode) 1 G Sa/s 200 MHz
16-bit (high resolution mode) 75 Msa/s 15 MHz
13
