CX3300 Current Waveform Analyzer
Quick Operation Guide
How to overlay multiple acquisitions
1. ON : Display > Persistence > Infinity
1-1. Click the “Display” icon on the Tool Palette.
1-2. Select “Persistence” on the Display tool palette.
1-3. Drag and drop the “Infinity” icon on the Display tool palette onto the
area of interest on the waveform.
1-1
1-2
Normal
1-3
Infinity
26
