CX3300 Current Waveform Analyzer
Quick Operation Guide
How to add an Annotation
1. Drag and drop the Display icon onto the target waveform.
1-1. Click the “Display” icon on the Tool Palette.
1-2. Click the “Annotations” tab.
1-3. Drag and drop the “Display” icon on the Display tool palette onto the
target waveform.
Tool Palette
1-1
1-2
Annotations
1-3
Drag & drop
No text
40
