2. How to perform User calibration ?
2-1. Click on the “Utilities” icon to open the Utilities menu.
2-2. Click “Configuration” to open the “Configuration” dialog box.
2-3. Click “User Calibration” to display the “Configuration>User Calibration”
screen.
2-4. Select the “Gain/Offset” or “Offset” radio button for the channel under
user calibration.
2-5. Click the “Execute” button of the channel.
2-6. The dialog box which asks you to connect the CX1100 input to the Aux
Out terminal is shown. If you are ready, click the “OK” button.
The user calibration will start.
After the user calibration finishes,
the ON/OFF switch will be available.
Note:
- The data is not cleared by turning the CX3300 off.
- Once you disconnect the CX1100 from the CX3300, the user calibration
data for this channel will be cleared.
Utilities
2-1
2-2
2-3
2-4
2-5
60
