Application Programs 6
Keysight E3633A and E3634A User’s Guide 177
To write an Excel macro you must first open a module in Excel. Go to the View
menu, choose Toolbars, and then select Control Toolbox. The Control Toolbox
dialog box appears. Select the Command button in the dialog box. Click cell A1
and drag across the cell B3. The “CommandButton1” box is created. To change
the button name, click the right mouse button on that button and then select
Properties. The Properties dialog box appears. In the Properties dialog, change
the “(name)” and “caption” to “Diode”. To try the example for characterizing a
diode, type “Voltages” in cell A4 and “Current” in cell B4. In cell A5 type 0.6. Fill in
the cells A5 to A15 in 0.02 increments so that cell A15 contains 0.8.
To enter the “Diode” macro example in this section, go to the View menu, choose
Toolbars, and then Visual Basic Editor icon. The “Code window” appears. Then
type the text as shown on page 139 into the “[Moudle1 (code)]” window. To enter
the declaration for Windows® 95/NT, go to the Insert menu, choose Module. The
“Module window” appears. Then type the text as shown starting on page 141. This
module will configure all of the overhead required to communicate with the power
supply over the interface. Choose the preferred interface by setting “bGPIB=” to
“True” or “False” and change the GPIB address or RS-232 port in the routine
“OpenPort( )” contained in the module.
To run the macro, return back to the Excel window and select the Run Macro
button in the dialog box and choose the macro name, and then click on the Run
button. The power supply will reset to power on condition and then step through
the voltages in the worksheet. After each step the current is measured, and
recorded in the worksheet.
Make any changes necessary to suit your application in the “Diode” module. You
must enter the information in the modules exactly as shown or error will be
generated. If several system errors occur while attempting to run a macro, you
may have to reboot your PC to get the GPIB port or RS-232 port to work properly.
To use the example with Window® 3.1, you will need to modify the declarations
at the top of the module. Change ‘visa32.dll’ to ‘visa.dll’ in all declarations.
