E4990A Disassembly Procedure
Rev.
5
C
A
D
B
1
Remove 0515-2044
T20
3
8
6
7
TRD MODULE & BNC PORT - TRD MODULE & BNC PORT DIS-ASSEMBLY (4)
A
2
Remove BNC Port Assembly
1 2 3
4 Disconnect (4ea)
4
BNC Port Assembly Removal Step
Disconnect (4ea)
5
5
Remove 0515-0430 (2ea)
T10 M3L6 Pan
6
Remove
TRD Module (E4990-62005)
6
