E4990A Disassembly Procedure
Rev.
3
C
A
D
B
1
Remove 0515-2044
T20
3
6
7
SOURCE MODULE - SOURCE MODULE DIS-ASSEMBLY (3) f90
A
2
Remove BNC Port Assembly
1 2 3
4 Disconnect (2ea)
4
Disconnect (4ea)
5
5
Remove connectors (2ea)
5/16” Open End Wrench
6
Remove 0515-0430 (2ea)
T10 M3L6 Pan
6
4
7
Remove
Source Module (E5061-62021)
7
