Verification and Calibration Appendix B
Series N8700 User’s Guide 127
Test Record – Keysight N8762A [600V, 8.5A, 5kW]
Keysight N8762A
Description
Report No _______________ Date __________________
Minimum Specs. Results Maximum Specs.
Voltage Programming & Readback
Minimum Voltage Vout
Measurement Readback
High Voltage Vout
Measurement Readback
1.2 V
Vout − 750 mV
599.4 V
Vout − 900 mV
_____________
_____________
_____________
_____________
2.1 V
Vout + 750 mV
600.6 V
Vout + 900 mV
CV Load Effect − 95 mV _____________ + 95 mV
CV Source Effect − 60 mV _____________ + 60 mV
CV Ripple and Noise
peak-to-peak
rms
N/A
N/A
_____________
_____________
500 mV
120 mV
Transient Response
Voltage @ 2 ms − 3V _____________ + 3V
Current Programming & Readback
Minimum Current Iout
Measurement Readback
High Current Iout
Measurement Readback
34 mA
Iout − 25.5 mA
8.466 A
Iout − 34 mA
_____________
_____________
_____________
_____________
85 mA
Iout + 25.5 mA
8.534 A
Iout + 34 mA
CC Load Effect − 8.5 mA _____________ + 8.5 mA
CC Source Effect − 4.3 mA _____________ + 4.3 mA
WARNING
Return the voltage and current settings to zero when verification is completed
Test Description N8762A Settings
Voltage Programming & Readback, Min Voltage 1.65V, 59.5mA
Voltage Programming & Readback, High Voltage 600V, 59.5mA
CV Load Effect, Source Effect, Ripple and Noise 600V, 8.5A
Transient Response 200V, from 0.85A to 7.65A
Current Programming & Readback, Min Current 59.5mA, 600V
Current Programming & Readback, High Current 8.5A, 600V
CC Load Effect, Source Effect 8.5A, 600V
N8762A Load Requirements
Current shunt
0.1
W 15 A
Use fixed resistor instead of load modules
70.6
W 5.5 kW
(or Amrel 5KW 600V 300A electronic load)
Fixed Resistor for CV Ripple and Noise
70.6W 5.5 kW
