Keysight PXA Series User Manual

6 Installation Note N9030-90058
Option EXM, External Mixing Upgrade Kit
Tools Required
❏ T-10 TORX Driver
❏ T-20 TORX Driver
❏ 5/16-inch torque wrench
❏ ¼-inch open-end wrench
❏ Diagonal cutters
❏ Agilent Calibration and Adjustment Software, N7814A (revision E.08.00 or later)
❏ Test equipment and computer supported by the X- Series Performance Tests and Adjustment
Software
❏ PXA Signal Analyzer Service Guide. This manual is available as:
— N9030A Option OBW or
— Agilent part number N9030-90030
❏ Microsoft Windows based personal computer with internet access and USB port
❏ USB storage device with > 2 GB free memory
Initial Instrument Functionality Check
Power on the instrument and allow the instrument to boot up. Run an alignment and display the
measurement screen. (The instrument will probably display a spectrum analyzer screen and you will
see the instrument sweeping.)
There should be no alignment failures. If there are failures, investigate and fix the problem before
continuing.
WARNING Before you disassemble the instrument, turn the power switch to Standby.
After the instrument has completely shut down, unplug the instrument.
Failure to unplug the instrument can result in personal injury.
CAUTION Electrostatic discharge (ESD) can damage or destroy electronic components. All
work on electronic assemblies should be performed at a static-safe workstation.
Refer to the documentation that pertains to your instrument for information about
static-safe workstations and ordering static-safe accessories.

Keysight PXA Series Specifications

General

Frequency Range	3 Hz to 50 GHz (depending on model)
Phase Noise	-136 dBc/Hz at 1 GHz and 10 kHz offset (typical)
Resolution Bandwidth	1 Hz to 10 MHz
Input Impedance	50 Ohm
Dimensions	177 mm (H) x 426 mm (W) x 470 mm (D)
