Installation Note N9030-90058 5
Option EXM, External Mixing Upgrade Kit
Installation Kit Parts List
Quantity
Description Agilent Part
Number
1 Adapter- Coaxial Straight Female-SMA to Female-SMA, 50 1250-1666
1 Washer, Lock, Internal Tooth, ¼ inch 2190-0067
1 Nut-Hex-Double-Chamfer 1/4-36-THD.125-IN-THK, Stainless Steel 2950-0223
1 50 Ohm Termination, SMA male 1810-0118
1 Opt EXM Cable Kit with Wire Markers (includes two versions of
cable W30, listed below)
N9030-60014
1 Cable Assembly, External Mixing, Front Panel (W29) N9020-20166
1 Cable Assembly, uW Front End to W29 (W17) (for use in RF and
microwave analyzers)
N9020-20132
1 Cable Assembly, mmW Front End to W29 (W17) (for use in
millimeter wave analyzers)
N9020-20167
1 Cable Assembly, Coaxial 275 mm LG (W30) (for use in millimeter
wave analyzers)
8120-2025
a
with ends
labeled ‘903’ and ‘13’
a. This cable is included in the Opt EXM Cable Kit with Wire Markers, p/n N9030-60014.
1 Cable Assembly, Coaxial 350 mm LG (W30) (for use in RF and
microwave analyzers)
8120-2027
a
with ends
labeled ‘903’ and ‘13’
1 Label, External Mixing N9030-80014
1 Label, Warning N9030-80018
5 Cable Ties 1400-0249
1 Entitlement Certificate 5964-5178
1 Entitlement Certificate Envelope 5967-7169
1 Installation Note This note

Keysight PXA Series Specifications

General

Frequency Range	3 Hz to 50 GHz (depending on model)
Phase Noise	-136 dBc/Hz at 1 GHz and 10 kHz offset (typical)
Resolution Bandwidth	1 Hz to 10 MHz
Input Impedance	50 Ohm
Dimensions	177 mm (H) x 426 mm (W) x 470 mm (D)
