Keystone KSTAP08MFC - PARTS DESCRIPTION; Component Identification (Front & Rear)

FRONT VIEW
PARTS DESCRIPTION
NOTE:
* The descriptions in this user manual are text and figures,
and may be slightly different to the promotion information
and actual appliance. Please refer to the real appliance
purchased. Thank you.
* The working temperature range of the air conditioner is
16~35ºC (60~95ºF) under cooling mode; 5~27ºC (41~80ºF)
under heating mode.
- 6 -
REAR VIEW
